Giá khuyến mại: | 16.907.000 đ |
Bảo hành: | 1 Năm |
Có 8 lựa chọn. Bạn đang chọn UDM SE:
KHUYẾN MÃI
Hỗ trợ & Tư Vấn TP.HCM
Hỗ trợ & Tư Vấn Hà Nội
MÔ TẢ SẢN PHẨM
Công ty Cổ Phần Đầu Tư Thương Mại H2K Việt Nam và Công ty TNHH Thương Mại Công Nghệ Trung Anh
là đại lý phân phối chính thức sản phẩm của UBIQUITI tại Việt Nam
ĐÁNH GIÁ VỀ SẢN PHẨM
Thông số kỹ thuật
Overview | |
---|---|
Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
UniFi Application Suite | Network: ✓ Protect: ✓ Access: ✓ Talk: ✓ Connect: ✓ |
Managed UniFi Devices | 100+ |
Managed Cameras | (24) HD (14) 2K (8) 4K |
Simultaneous Users Connected | 1,000+ |
Max. WAN Port Count | 8 |
Default WAN Ports | (1) 10G SFP+ (1) 2.5 GbE RJ45 |
Port Layout | 1 GbE RJ45: 8 (1G/100M/10M) 2.5 GbE RJ45: 1 (2.5G/1G/100M/10M) 10G SFP+: 2 (10G/1G) |
IDS/IPS Throughput | 3.5 Gbps |
Form Factor | Rack mount (1U) |
Redundancy | Shadow Mode (VRRP) Gateway Failover DC Power Backup |
Security | |
Stateful Firewall | ✓ |
Application-Aware Layer 7 Firewall | ✓ |
DPI & Traffic Identification | ✓ |
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) | ✓ |
Content Filtering | ✓ |
Intrusion Prevention (IPS/IDS) | ✓ |
Ad Blocking | ✓ |
IDS/IPS Signatures | 55,000+ with CyberSecure |
VLAN/Subnet-based Traffic Segmentation | ✓ |
VPN & SD-WAN | |
License-Free SD-WAN | ✓ |
Site-to-Site VPN | Site Magic: ✓ IPsec: ✓ OpenVPN: ✓ |
VPN Server | Identity Endpoint One-Click VPN: ✓ Teleport Zero-Configuration VPN: ✓ WireGuard: ✓ OpenVPN: ✓ L2TP: ✓ |
VPN Client | OpenVPN: ✓ WireGuard: ✓ |
Networking | |
Multi-WAN Load Balancing | ✓ |
Shadow Mode (VRRP) High Availability | ✓ |
Dynamic Routing | OSPF: ✓ BGP: ✓ |
Advanced QoS | ✓ |
Multicast DNS (mDNS) | ✓ |
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) | ✓ |
Integrated RADIUS Server | ✓ |
RADIUS over TLS (RadSec) | ✓ |
Additional Internet Failover with UniFi LTE Backup | ✓ |
Internet Quality and Outage Reporting | ✓ |
MAC Address Table Size | 4,000 |
Policy-based WAN and VPN Routing | ✓ |
Customizable DHCP Server | ✓ |
IPv6 ISP Support | ✓ |
IGMP Proxy | ✓ |
Hardware | |
NVR Storage | (1) 3.5" NVR HDD bay Built-in 128 GB SSD for Faster Experience |
PoE Budget | 180W |
Max. PoE Wattage per Port by PSE | PoE: 15.4W PoE+: 30W |
Voltage Range PoE Mode | PoE: 44-57V PoE+: 50-57V |
Max. Power Consumption | 50W (Excluding PoE Output) |
Power Method | (1) Universal AC input, 100—240V AC, 4.4A Max., 50/60 Hz (1) USP-RPS DC input, 52V DC, 3.94A |
Power Supply | AC/DC, internal, 240W |
Supported Voltage Range | 100—240V AC |
Processor | Quad-core ARM® Cortex®-A57 at 1.7 GHz |
System Memory | 4 GB |
On-board Storage | 16 GB eMMC 128 GB SSD (Integrated) |
Weight | 5 kg (10.9 lb) |
Enclosure Material | Aluminium CNC, SGCC steel |
Mount Material | SGCC steel |
LCM Display | 1.3" touchscreen |
Management | Ethernet Bluetooth |
LEDs | Ethernet: ✓ SFP+: ✓ RPS: ✓ PSU: ✓ HDD: ✓ |
Button | (1) Factory-reset |
ESD/EMP Protection | Air: ± 15kV, contact: ± 8kV |
Ambient Operating Temperature | -10 to 40° C (14 to 104° F) |
Ambient Operating Humidity | 5 to 95% noncondensing |
NDAA Compliant | ✓ |
Certifications | CE, FCC, IC, Anatel, SRRC |
